Parts

The tables below indicate our most commonly requested PARTS.

For pricing on these or information on other parts, please contact:
your Maintainer Dealer or our Service Department.

Door Parts

Compressor Parts

> Hydraulic Parts

Remote Control Parts

PSS Parts

Lights & Misc

Crane Parts

Drawer Parts

> Decals





DOOR PARTS

Part # Description
Parts_-_Door_parts_-_body_hinge.png 052052
Body Hinge Pin Kit (includes gasket, bolt, washer, nut)
003124 Body Hinge Pin Only
Parts_-_Door_parts_-_Door_Hinge.png 052053
Door Hinge Kit (includes bolts, washers, gaskets, nuts)
003125 Door Hinge Only
Parts_-_Door_parts_-_Gas_Door_Spring.png 003184
Gas Door Spring
007945 Large Gas Spring for Slide-Top Covers
Parts_-_Door_parts_-_Door_Latch.png 012743
LH Door Latch
012742 RH Door Latch

Uses J210 Key
Parts_-_Door_parts_-_Replacement_Lock.png 050260 Replacement Lock for 012742 & 012743
Door_parts_-_Tumbler_010622.png 051587
J202 Lock Tumbler
010622
J203 Lock Tumbler
051132
J206 Lock Tumbler
051133
J207 Lock Tumbler
051134
J208 Lock Tumbler
051135
J209 Lock Tumbler
051243 J223 Lock Tumbler
Parts_-_Door_parts_-_Door_Rods.png 007389 Door rods for 012742 & 012743
Parts_-_Door_parts_-Dust_Cover_fits.png 000285 Dust Cover
fits 012742, 012743, 000286 & 000287
Parts_-_Door_parts_-_drip_rail.png 009191
Drip Rail - 12'
003164 Rubber Door Bumper (Rubber Stop)
Parts_-_Door_parts_-LH_door_latch.png 000286
LH Door Latch
000287
RH Door Latch
003149 Door Rods for above latches
(uses CH545 Key - gasket must be ordered separately)
Parts_-_Door_parts_-D_ring_latch_gasket.png 003067 D-ring Latch Gasket
Parts_-_Door_parts_-Replacement_lock.png 003136 Replacement Lock for 000286 & 000287
--- Keyed CH545
Door_parts_-_T_handle_latch_051345.png 051345 "T" Handle Latch
Parts_-_Door_parts_-Replacement_lock_for_T_Handle.png 003142 Replacement Lock for "T" Handle Latches
Parts_-_Door_parts_-weather_stripping.png 019491 Compartment Weather Stripping (note: old part 013765 is obsolete)
Door_parts_-_Compartment_plug_006921.jpg 006921 1-1/8" Compartment Plug
Parts_-_Door_parts_-Double_door_seal.png 016340 Double Door Seal
Parts_-_Door_parts_-Spring_door_check.png 002949 Spring Door Check
Door_parts_-_Oxy_Door_Vent_000271.png 000271 Oxy Acetylene Door Vent

> RETURN TO TOP OF PAGE




HYDRAULIC PARTS

Part # Description
Pumps__Filters_-_HP_filter_assy.png 000263
High Pressure Filter Assembly - Includes Filter
003006
High Pressure Filter
007241 O-ring
Change recommended every 12 months
Pumps__Filters_-_small_return_filter_2.5_x_5.png 003004
Small Return Filter 2.5" x 5"
050290
O-ring
051582 O-ring for Black Return Filter Housing 013340
Change recommended after first 50 hours of use - then every 12 months
Pumps__Filters_-_Large_return_filter_4_x_8.png 003009
Large Return Filter 4" x 8"
008996 O-ring
Change recommended after first 50 hours of use - then every 12 months
Pumps__Filters_-_Large_return_filter_4_x_9.png 007364
Large Return Filter 4" x 9"
008996 O-ring
Change recommended after first 50 hours of use - then every 12 months
019382.jpg 019382 Composite Tank Return Filter
Pumps__Filters_-_LH_2.77_Eaton_small_pump.png 002862
LH 2.77 Eaton Small Pump (70423-LCE H200134)
050039
Shaft Seal
050041 Complete Seal Kit
Pumps__Filters_-_RH_2.77_Eaton_Small_Pump.png 002854
RH 2.77 Eaton Small Pump (70423-RDC H200758)
050039
Shaft Seal
050041 Complete Seal Kit
Pumps__Filters_-LH_3.0_420_Eaton_pump.png 008225 LH 3.0 420 Eaton Pump
Pumps__Filters_-_RH_3.0_420_Eaton_Pump_08226.png 008226 RH 3.0 420 Eaton Pump
Pumps__Filters_-Gresen_Valve_Coil.png 002924 Gresen V20 Valve Coil / Solinoid
Hydraulic_parts_-_SDF_valve_handle_mount_051592.png 051592 SDF Valve Handle Mount
Hydraulic_parts_-_VDM_Valve_Unloader_016076.jpg 016076 VDM Valve Unloader
Hydraulic_parts_-_SDF_unloader_valve_008853.png 008853 SDF Unloader Valve
Pumps__Filters_-Hydraulic_res_sight_gauge.png 003091 Hydraulic Res Sight Gauge
Pumps__filters_-_Return_Filter_Gauge.png 013148 Return Filter Gauge
Hydraulic_parts_-_red_lube_tank_breather_element_050633.png 050633 Lube Tank Breather Element (RED)
Lube_parts_-_Donaldson_filler_breather_014695.jpg 014695 Donaldson Filler Breather
Hydraulic_parts_-_Lube_tank_cap_003227.png 003227 Lube Tank Cap

> RETURN TO TOP OF PAGE




PSS PARTS

Part # Description
PSS_Parts_-_PSS_fan_box.png 012333 PSS Fan Box
PSS_Parts_-_Coupler_Nut.png 010101 Coupler Nut
PSS_Parts_-_Coupler_stud.png 010102 Coupler Stud
PSS_Parts_-_Filter_element.png 010043 Filter Element
PSS_Parts_-_Filter_cover.png 010044 Filter Cover
PSS_Parts_-_Filter_base.png 010045 Filter Base
PSS_Parts_-_Current_production_PSS_fan_element.png 012052 Current Production PSS Fan Element - change recommended periodically according to working environment
PSS_Parts_-_Filter_Knob.jpg 018571 PSS Filter Knob
PSS_Parts_-_Bolt-On_PSS_Kit_021290.jpg 021290 Bolt-on PSS Kit

> RETURN TO TOP OF PAGE


CRANE PARTS

Part # Description
Crane_Parts_-_Anti_2_block_switch.png 000641 Anti-two-block Switch
Crane_Parts_-_Hex_boom_anti_2_bock_switch.png 007651 Hex Boom Anti-two-block Switch
Crane_Parts_-_DUAL_Sheave_Old_Anti_2_Block_Kit.jpg 000766 DUAL Sheave Old style Anti-Two-Block Kit
Note: Does not include Reel
Crane_Parts_-_Single_Sheave_Old_Anti_2_Block_Kit.png 000772 Single Sheave Old Style Anti 2 Block Kit
Note: Does not include Reel
Crane_Parts_-_Crane_Degree_Indicator.png 012211
Crane Degree Indicator
012322
Nut
012178
Nylon Shoulder Washer
012897 Flat Washer
Crane_Parts_-_Spring_A2B.jpg 007652 Spring A2B
Crane_Parts_-_Hex_boom_anti_2_block_reel.png 011438 Hex Boom Anti-two-block Reel
Crane_Parts_-_Old_anti_2_block_reel.png 007928 Old Anti-two-block Reel
Crane_Parts_-_Load_block_3-10000_Series_cranes.png 016635 Load Block 3000 - 10000 Series Cranes
Crane_Parts_-_Wire_rope.png 005069
3216-20 Wire Rope
003201
4520 / 5220 Wire Rope
007360
6000 / H7024 / 8000 Wire Rope
003200
6220 / 7220 / 12000 / 14000 Series Wire Rope
008073
10000 Series Wire Rope
014294
H6520 Wire Rope
015859
H10025 / H10034 Wire Rope
013052
H12025 Wire Rope
017267 H14025 Wire Rope
Crane_Parts_-_slide_on_outrigger_pad.png 010583 Slide-On Outrigger Pad
Crane_Parts_-_Bulls_Eye_Level.png 008296 Bullseye Level Gauge
Use Hardware 008318, 008298, 008317
Crane_Parts_-_Outrigger_Cap.png 013510
4" x 4" Outrigger Cap
010567 5" x 5" Outrigger Cap
Crane_Parts_-_Valve_Well_Lid_T_Handle.png 003131 Valve Well Lid "T" Handle
Crane_Parts_-_Large_Outrigger_Down_Cylinder_007777.jpg 007777 Large Outrigger Down Cylinder
Fits 5x5 Tube
Crane_Parts_-_Bottom_Outrigger_Pin_000004.jpg 000004
Bottom Outrigger Pin for Cylinder 007777
003245 Snap Rings
Crane_Parts_-_Top_Outrigger_Pin_001619.jpg 001619 Top Outrigger Pin for Cylinder 007777

> RETURN TO TOP OF PAGE


DECALS

Part # Description
Decals_-_Medium_Maintainer_Decal.jpg 002264 Medium Maintainer Decal
Decals_-_Large_Maintainer_Crane_Boom_Decal.jpg 002265 Large Maintainer Crane Boom Decal
Decals_-_6000_series_Capacity_Chart.jpg 008135 6000 Series Crane Capacity Chart
Decals_-_10000_series_Crane_ID.jpg 008014 10000 Series Crane ID Decal
Decals_-_10000_series_Capacity_Chart.jpg 007791 10000 Series Crane Capacity Chart
Decals_-_Warning__Safety_Kit.jpg 011297 Warning & Safety Decal Kit
Decals_-_Outrigger_Warning_Stand_Clear.jpg 018343 Outrigger Warning Decal - Stand Clear
Decals_-_Push_Button_Remote_Mag.jpg 051762 Push Button Remote Mag Decals

COMPRESSOR PARTS

Part # Description
Compressor_parts_-_17_gallon_air_tank.png 000012 17-Gallon Air Tank
Compressor_parts_-_Air_Tank_Cable_Drain.png 002171 Air Tank Cable Drain
Compressor_parts_-_165psi_pop_off_valve.png 002173 165 psi Air Tank Pop-Off Valve
Quincy_Fan.jpg 050802 Quincy Cooler Fan Only
Compressor_parts_-quincy_air_end.png 005765 Quincy Air End
Compressor_parts_-_Quincy_update_compressor.png 006701 Quincy Update Compressor
**Does not include hydraulic motor, flow control or motor mount bracket
Compressor_parts_-_complete_quincy_compressor.png 006906 Complete Quincy Compressor
Compressor_parts_-quincy_air_compressor_motor.png 018354 Quincy Air Compressor Motor
Compressor_parts_-_AC_solenoid_operated_flow_control.png 002905 A/C Solenoid Operated Flow Control
(use 014705 with NO check)
A/C Red Block Solenoid Flow Control
050047
Cartridge DSL101C
050077 Coil S10LPD012
Compressor_parts_-load_genie_air_check_valve.png 002174 Quincy Compressor unloader valve
(Load Genie Air Check Valve)
Compressor_parts_-quincy_love_joy_coupler.png 050174 Quincy Compressor Love Joy Coupler
Compressor_parts_-Love_joy_spider.png 003055
Love Joy Spider
003058 Love Joy Coupler for .625 Hydraulic Motor shaft
Compressor_parts_-_quincy_compressor_air_filter.png 007086 Quincy Compressor Air Filter - change recommended every 12 months
Compressor_parts_-_quincy_valve_repair_kit.png 050076 Quincy Valve Repair Kit
Compressor_parts_-_IR_Doosan_compress_air_filter.png 050205 IR / Doosan 40 CFM Compressor Air Filter
Compressor_parts_-_Vanair_RC40_air_filter.png 051241 Vanair RC40 Air Filter - change recommended every 12 months
Lube_parts_-_quincy_pressure_switch.png 004657 Quincy Pressure Switch
Lube_parts_-_IR_Doosan_pressure_switch.png 050071 IR / Doosan Pressure Switch
Compressor_parts_-_Vanair_RC40_pressure_switch.png 014948 RC40 Pressure Switch
Lube_parts_-_IR_Doosan_compressor_fan.png 008559
IR / Doosan Compressor Fan
051408 RC40 Cooling Fan
Lube_parts__-_Complete_service_body_FRL.png 016041 Complete Service Body Filter Regulator Lubricator (FRL) with Fittings
Lube_parts__-_complete_lube_FRL.png 016045 Complete Lube Truck Filter Regulator Lubricator (FRL)
Lube_parts_-_FRL_only.png 015481 Filter Regulator Lubricator (FRL) Only
Compressor_parts_-_Wilkerson_Sight_Gauge.png 051557 Wilkerson Sight Gauge
Compressor_parts_-_Wilkerson_Dome.png 051551 Wilkerson Dome
Compressor_parts_-_Wilkerson_FRL_Diaphragm_Kit_051584.jpg 051584 Wilkerson FRL Diaphragm Kit

> RETURN TO TOP OF PAGE


REMOTE CONTROL PARTS

Part # Description
Remote_Control_-_Legacy_crane_wireless_kit.png 014550
Legacy Crane Wireless Kit
014549 Wiring Harness for above Kits
Remote_Control_-_non_proportional_remote_head.png 000384 Non Proportional Remote Head
Remote_Control_-_proportional_remote_head.png 000385 Proportional Remote Head
Remote_Control_-_remote_trigger.png 000430 Remote Trigger
Remote_Control_-_remote_circuit_board.png 000628 Remote Circuit Board
Remote_Control_-_remote_function_switch.png 000631 Corded Remote Function Switch
Remote_Control_-_remote_on_off_switch.png 000633 Corded Remote On/Off Switch
Remote_Control_-_remote_cord_grip.png 000620 Remote Cord Grip
Remote_Control_-_remote_cord_connector.png 000396
Remote Cord Connector (cannon plug)
000397 Valve Side Remote Cord Connector
Remote_Control_-_6'_lead.png 000380 6' Lead to Crane Valve
remote_wiring_cable.jpg 004885
Corded Remote Wiring Cable
051231 Remote Cable with Connector (000396) - will have to be built
009876 Taillight Junction Box
Remote_Control_-_Inline_Wired_remote_007943.jpg 007943
Inline Proportional Crane Wired Remote
007944
Full Proportional Crane Wired Remote
050150 NON Prop Remote w/o Duetsch

> RETURN TO TOP OF PAGE


LIGHTS & MISC

Part # Description
Lights_-_LED_Flood_Light_016764.jpg 016764 LED Flood Light
Lights_-_Magnetic_LED_Flood_Light_016765.jpg 016765 Magnetic LED Flood Light
Lights_-_45_inch_LED_self_adhesive_strip_light.png 014876 24" LED Self-adhesive Strip Light
Lights_-_24inch_LED_self_adhesive_strip_light.png 014877 45" LED Self-adhesive Strip Light
Remote_Control_-_rocker_switch_body.png 003599
Rocker Switch Body
007286 Rocker Switch Lens
Remote_Control_-_fuse_block.png 000448 Fuse Block
Remote_Control_-_Main_power_solenoid.png 000505 Main Power Solenoid
Remote_Control_-_12-24_volt_switch.png 000644 12/24 Volt Push Pull Switch
bolt_on_rear_step.png 013577 Bolt-On Rear Step
Lights__Misc_-_BNSF_fold-up_step.png 050757 BNSF Fold-Up Step
Aluminum_Step.png 019482 Pull-Out Aluminum Step
Lights__Misc_-_fender_flare_kit.png 051899 2-Ton Fender Flare Kit
Misc_-_Compartment_Shelf.jpg 001323 Compartment Shelf - fits a 24" box
*Call 866-781-3259 for other sizes
Misc_Parts_-_BNSF_Dri_Deck.jpg 013583 BNSF Dri Deck
Chassis_-_jump_start_system_2.png 052043 12-24 Jump Start Kit with 500 AMP 30' cables

> RETURN TO TOP OF PAGE


DRAWER PARTS

Part # Description
Drawer_parts_-_5_drawer_tool_box.png 013225
5-Drawer DuaLock Tool Box
Top Shelf Included 18" wide x 29" tall s 18" deep
Five 4" Drawers
Drawer_parts_-_7_drawer_tool_box.png 013227
7-Drawer DuaLock Tool Box
Top Shelf Included 29" wide x 41" tall x 18" deep
Five 4" drawers, one 5" drawer, one 6" drawer
Drawer_parts_-_7_drawer_tool_box_013757.png 013757
7-Drawer DuaLock Tool Box
Top Shelf Included 29" wide x 41" tall x 18" deep
Three 3" drawers, three 5" drawers, one 7" drawer
Dualock_drawer_new_design_293x220.png 020017
7-Drawer DuaLock Tool Box
Top Shelf Included 29" wide x 41" tall x 18" deep with side-to-side dividers
three 3" drawers, three 5" drawers, one 6" drawer
DuaLock Replacement Rollers
012732
LH Drawer Roller
013145 RH Drawer Roller
drawer_parts_-_HD_EZ_latch_drawer_rollers.png 050755 HD EZ Latch Drawer Rollers
Drawer_parts_-_SD_EZ_latch_drawer_rollers.png 050769 SD EZ Latch Drawer Rollers
Drawer_parts_-_HD_old_style_steel_drawer_rollers.png 004921 HD Old Style Galvanized Steel Drawer Rollers
Drawer_parts_-_SD_old_style_steel_drawer_rollers.png 004922 SD Old Style Galvanized Steel Drawer Rollers
Drawer_Parts_-_EZ_Latch_Drawer_Hook_050749.jpg 050749 EZ Latch Drawer Hook (for older style drawers)

> RETURN TO TOP OF PAGE


The tables above indicated our most commonly requested PARTS. For pricing on these or information on other parts, please contact your Maintainer Dealer, or e-mail jkaptein@maintainer.com.

Door Parts                                 • Compressor Parts
Pumps & Filters                          • Remote Control Parts
PSS Parts                                   • Lights & Misc
Crane Parts                                 • Drawer Parts
Decals
